WELKE UNIT ZIT IN WELKE BOX?

-

LUIDSPREKERBEZETTING IN PHILIPS' VOORNAAMSTE VINTAGE BOXEN

(Met dank aan de auteur van de onderstaande lijst: THOMAS BAUR - MFB Freaks)

22AH124: AD5053: AD3800AM (800 ohm)
22AH403: AD8082M4 / fres: 143Hz / 12L / 13W
22AH404: AD70611/W8 / AD0147/T15 / fc-o: 5000Hz / fres: 29&86Hz / 14L / 20W
22AH462: AD7066/W4 / AD0141/T8 / fc-o: 1500Hz / fres: 90Hz / 7L
22AH463: AD8066/W4 / AD0163/T8 / fc-o: 1300Hz / fres: 85 Hz / 15L(=AH485)
22AH466: AD8066/W4 / AD0211/SQ8 / AD0163T8 / fc-o: 900;3000Hz / fres: 65 Hz / 22L / (oud type AD8066) (=AH486)
22AH466: AD8066/W4 / AD0211/SQ8 / AD0163T8 / fc-o: 1000;3000Hz / fres: ? / 22L (nieuw type AD8066)
22AH467: AD8066/W4 / AD8000 / AD0211/SQ8 / AD0163T8 / fc-o: 900;3000Hz / fres: ? / 32L (oud type AD8066)
22AH467: AD8066/W4 / AD8000 / AD0211/SQ8 / AD0163T8 / fc-o: 1000;3000Hz / fres: 45 Hz / 32L (nieuw type AD8066)(=AH487)
22AH468: AD8067/W4E / AD8067/W4E / AD0210/SQ8 / AD0163T15 / fc-o: 900;3000Hz / fres: 45 Hz / 32L(=AH488?)
22AH482: AD70611/W8 - AD0143/T15S / fc-o: 5000Hz / fres: 86Hz / 12L / 35W (4&8 Ohm uitvoeringen)
22AH482: AD70611/W4 - AD0143/T8 / fc-o: 5000Hz / fres: 86Hz / 12L / 35W (4&8 Ohm uitvoeringen)
22AH483: AD80603/W8 - AD0142/T8S
22AH483: AD80603/W8 / AD0142/T15 / fc-o: 3800Hz / fres: 88Hz / 16L / 40W (4&8 Ohm uitvoeringen)
22AH484: AD80603W8 / AD5062/SQ8 / AD0164T8
22AH488: AD8067/W4e - AD0211/SQ8 - AD0163/T15
22AH489: AD80652/W8 / AD02111SQ8 / AD0144T15 / fc-o: 950;5000Hz / fres: 16&65Hz / 32L / 60W (4&8 Ohm uitvoeringen)
22AH491: AD8082/M4 / fres: 75Hz / 12L / 13W
22AH492: AD7061/W4 / AD2095T8 / fc-o: 6000Hz / fres: 23&87Hz / 14L / 20W
22AH494: AD10650/W8 / AD02112SQ8 / AD01635T15 / fc-o: 600;6000Hz / fres: 54Hz / 40L / 80W
22AH495: AD12200/W8 / AD02112SQ8 / AD01635T15 / fc-o: 750;5500Hz / fres: 53Hz / 55L 200W
22AH585: AD70651/MFB4 -
22AH586: AD81671/MFB4 -
22AH587: AD81671/MFB4 - AD02110/SQ8 - AD0163/T15
22AH587: AD81671/MFB4 - AD02160/SQ8 - AD0163/T15
22GL565: AD3703/S(?) - AD3506/SM(?)
22RH410: AD5061/M4 / fres: 115Hz / 4L / 10W
22RH411: AD5061/M4 / fres: 110Hz / 7L / 10W
22RH412: AD7060/M4 / fres: 95Hz / 12L / 10W
22RH413: AD7065/W4 / AD0160T8 / fc-o: 1200Hz / fres: 90 Hz / 4L / 20W
22RH414: AD7060/M8 / fres: 95Hz / 12L / 10W
22RH422: AD7061/M4 / fres: 95Hz / 12L / 20W
22RH423: AD8060/W4 / AD0160T4 / fc-o: 2000Hz / fres: 75 Hz / 15L / 20W
22RH426: AD8065/W4 / AD5060SQ4 / AD0160T4 / fc-o: 500;5000Hz / fres: 75 Hz / 25L
22RH427: AD8065/W8 / AD8065W8 /AD5060SQ4 / AD0160T4 / fc-o: 500;5000Hz / fres: 44 Hz / 35L
22RH443: AD8061/W4 / AD0140T4 / fc-o: 3000Hz / fres: 105Hz / 12L / 20W
22RH452: AD7066/W4 / AD0160T8 / fc-o: 1200Hz / fres: 105 Hz / 4L / 30W
22RH453: AD8066/W4 / AD0161T8 / fc-o: 1500Hz / fres: 65 Hz / 15L
22RH456: AD8066/W4 / AD0210SQ4 / AD0161T8 / fc-o: 700(serv doc:580) ;3000Hz / fres: 55 Hz / 25L
22RH457: AD8066/W4 / AD8000(?) / AD0210SQ4 / AD0161T8 / fc-o: 700(serv doc:580) ;3000Hz / fres: 28&65Hz / 35L
22RH480: AD1055W8 / AD35015SM5 / SHH17SD (Coral) / fc-o: 500;4000Hz / fres: 45Hz / 35L / 40W
22RH481: AD5061M8 / fres: ? / 7L / 6W
22RH482: AD? / fres: ? / 12L / ?W
22RH491: AD7065/W8 / AD0160/T8 / fc-o: 1500Hz / fres: 70Hz / 7L / 20W
22RH493: AD8060/W8 / AD0160/T8 / fc-o: 1500Hz / fres: 60Hz / 15L / 20W (zowel 4 als 8 Ohm uitvoering blijkbaar)
22RH496: AD8065W8 - AD5060W8 - AD0160T8, 25L
22RH497: AD1055/W8- AD5060/W8 - AD0160T8, 32L Fres= 55Hz
22RH499: AD1256/W8 / AD5060SQ8(x4) / AD0160T8(x4) / fc-o: 700;3000Hz / fres: 40 Hz / 80L

22RH532 AD8065/MFB4 - 5060/SQ8 - AD0160/T8

22RH532 AD8067/MFB4 - 5060/SQ8 - AD0160/T8

22RH541: AD7066/MFB4 - AD0140/T8 <PL01

22RH541: AD7066/MFB4 - AD0162/T8 <PL02
22RH541: AD7066/MFB4 - AD0140/T8 <PL03
22RH541: AD70651/MFB4 - AD????/T? <PL0?
22RH544: AD8067/MFB4 - AD0210/SQ8 - AD140/T8
22RH544: AD8067/MFB4 - AD0211/SQ8 - AD163/T8
22RH545: AD12100/MFB4 - AD0210/SQ - AD0162/T8
22RH567: AD10100/MFB4 - AD0211/SQ8 - AD163T8
FB815: AD (of 00)- 00401T8, 40409Sq8DC, 80629W8
FB820: AD (of 00)- 00401T8, 40629Sq8DC(?), 70609W15DC (2x)
FB821: AD(of 00)- 21601RT8, 40629Sq8DC, 70609W15DC (2x)
FB825: AD(of 00)- 21601RT8, 51654Sq8DC, 80669W15DC (2x)
FB840: AD70604/W12 5 (2X) (woofer 9,8 ohm) (met dank aan de Hr. H. Huijnen) mid- & hoogdrivers nog onbekend
F9412: AD70612/W8 - AD6101 - AD1433/T8
F9414: AD70612/W8
F9430: AD80681/W8 - AD11430/T8
F9432:
F9434: AD80603
F9436: AD80111/W15 (2x) - AD02170/SQ8 - AD21600/RT8
F9416:
F9638: AD80...MFB. - AD02170SQ8 - AD21600RT8
F9818: AD10200W8 - AD70652W8 - 02112SQ8 - AD1635T15
F9819: AD12240W8 - AD70652W8 - 02112SQ8 - AD1635T15
